AudioCodes MP-112 gateway/controller 10, 100 Mbit/s
- Leverage investment in legacy analog telephone, modem, and fax systems – easing VoIP migration
- Secured zero-touch provisioning, useful for large-scale deployments
- Standalone Survivability (SAS) keeps your business running in the event of a network failure
- Support for 2 to 24 analog ports
- T.38 fax compliant
- Rich subscriber feature set: 3-way conference with local mixing, call pickup, hunt groups, call forwarding, call hold and call transfer
- Advanced telephony features such as long-haul, metering tones generation, country dependent MWI and Caller ID for true integration with the existing telephony infrastructure
AudioCodes’ MediaPack 1xx series of analog VoIP gateways offer service providers and enterprises superior voice technology for connecting legacy telephones, fax machines and PBX systems with IP telephony networks and IP-PBX systems.
The MediaPack 1xx gateways are fully interoperable with leading softswitches and SIP servers.
| Design |
| LED indicators |
Yes |
| Product colour |
Black |
| Features |
| Voice codecs |
G.711alaw, G.711ulaw, G.722, G.723.1, G.726, G.727, G.729A, G.729B |
| Protocols |
| Supported protocols |
RTP (RFC 3550), SRTP (RFC 3711), RTCP (RFC 3550), RTCP-XR (RFC 3611) , |
| Supported network protocols |
IPV4/IPV6, DiffServ, TOS |
| VoIP protocols |
G.168 – 2004 |
| Management protocols |
Web GUI, SSH/Telnet, SNMP v2/v3, |
| Network |
| Modulation |
DTMF |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Security |
| VLAN support |
Yes |
| Security algorithms |
HTTPS, SRTP, TLS |
| Ports & interfaces |
| Ethernet LAN (RJ-45) ports |
1 |
| Interface |
2 FXS |
| Power |
| Input frequency |
50 – 60 Hz |
| Input voltage |
100 – 240 V |
| Weight & dimensions |
| Weight |
500 g |
| Width |
172 mm |
| Depth |
220 mm |
| Height |
42 mm |
| Operational conditions |
| Operating relative humidity (H-H) |
10 – 90% |
| Storage temperature (T-T) |
-25 – 85 °C |
| Operating temperature (T-T) |
5 – 40 °C |
