Axis 02208-001 PoE adapter Fast Ethernet, Gigabit Ethernet 56 V

Original price was: £139.99.Current price is: £46.55.

Compare
Add to wishlist
SKU: US-15329997717886 Category:
Description

Axis 02208-001 PoE adapter Fast Ethernet, Gigabit Ethernet 56 V

  • 24 V AC and 10-28 V DC input; Compatible with Axis PoE devices; Flexible installation; IEEE 802.3af and 802.3at output; Plug-and-play

AXIS 30 W Midspan AC/DC is for installations where mains power is not an option. With a power input of either 10-28 V DC or 24 V AC, it can deliver up to IEEE 802.3at (30 W) to your network device. 24 V AC can be needed in harsh environments where new cabling or installations are not possible and you need to retrofit box, dome or PTZ cameras. 10-28 V DC can be used where battery back-up is needed or for solar-powered installations. Or when the network device is built in another equipment and is powered directly from it.

Network
Networking standards IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates 10,100,1000 Mbit/s
Ethernet interface type Fast Ethernet, Gigabit Ethernet
Features
LED indicators Yes
Wall mountable Yes
Product colour Black
Ports & interfaces
RJ-45 output ports 1
RJ-45 input ports 1
Ethernet LAN (RJ-45) ports 2
Power
Input voltage 10-18 V
Output power 30 W
Power over Ethernet (PoE) voltage 56 V
Certificates
Certification IS 13252, IEC/EN/UL 62368-1, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, IEC 60068-2-6, IEC 60068-2-27, 55024, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, FCC Part 15 Subpart B Class A, KC KN32 Class A, KC KN35, RCM AS/NZS CISPR 32 Class A, VCCI Class A, EAC
Sustainability
Doesn’t contain PVC
Operational conditions
Storage temperature (T-T) -40 – 75 °C
Operating relative humidity (H-H) 0 – 95%
Operating temperature (T-T) -20 – 70 °C
Weight & dimensions
Weight 233 g
Height 37 mm
Depth 164 mm
Width 65 mm
Logistics data
Harmonized System (HS) code 85044095
