Bolide MVR-ADAS advanced driver-assistance system (ADAS) ADAS camera
Most traffic accidents are due to human error. These advanced safety systems were developed to automate and enhance aspects of the driving experience to increase safety and safe driving habits. ADAS has been shown to reduce the number of accidents on the road by also reducing the possibility of human error.
Advanced driver assistance systems are technological features that are designed to increase the safety of driving a vehicle. These systems use a human-machine interface to enhance the driver’s ability to react to hazards on the road. These systems increase safety and driver reaction times through automated and early warning
systems. Studies show that more than 80% of traffic collisions are caused by human error and a 2-second early warning can prevent 99% of accidents.
The ADAS system is a camera located in the cabin of the vehicle that captures the image of the road controlling, monitoring, and monitoring all elements on the road that may become potentially dangerous and allowing a timely response from the driver, providing a more efficient driving experience. safe and reliable.
| Features |
| Preset modes |
Lane departure warning, Front collision warning, Headway distance, Pedestrian collision warning |
| Installation type |
Windshield mount |
| Product colour |
Black |
| Connectivity technology |
Wired |
| Product type |
ADAS camera |
| Camera |
| LED type |
IR |
| Night vision |
Yes |
| Signal-to-Noise Ratio (SNR) |
80 dB |
| Minimum illumination |
0.001 lx |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Camera resolution |
1920 x 1080 pixels |
| Image sensor size |
1/2.9″ |
| Display |
| Built-in display |
No |
| Power |
| DC output current |
0.065 A |
| DC output voltage |
12 V |
| Power source type |
DC |
| Weight & dimensions |
| Weight |
100 g |
| Depth |
43 mm |
| Height |
68 mm |
| Width |
105 mm |
| Operational conditions |
| Operating relative humidity (H-H) |
0 – 90% |
| Operating temperature (T-T) |
-25 – 75 °C |
