DeepCool Morpheus WH Tower White
- Tower PC Gaming
- ATX, micro ATX, Mini-ATX, EATX
- Supported HDD sizes: 2.5,3.5″ SSD form factor: 2.5″
- Number of 2.5″ bays: 3 Number of 3.5″ bays: 2
- Side window Illumination Multi Tempered glass panel(s) Anti-dust filter
- ABS, SPCC, Tempered glass
- White
Modularity has a new face, and it comes to us in the form of DeepCool’s internally reconfigurable ATX+ chassis: the MORPHEUS WH. With incomparable compatibility and a spacious layout, the MORPHEUS WH is the best option for the DIY modder or the casual PC enthusiast.
MORPHEUS WH
The Internal Shapeshifter
MORPHEUS WH
Modularity has a new face, and it comes to us in the form of DeepCool’s internally reconfigurable ATX+ chassis: the MORPHEUS WH. With incomparable compatibility and a spacious layout, the MORPHEUS WH is the best option for the DIY modder or the casual PC enthusiast.
A NEW TAKE ON MODULARITY
If sticking to the same system layout for years sounds boring, the MORPHEUS WH is exactly what you are looking for. Easily switch between the classic single chamber configuration and the dual chamber layout with a simple switch of a few parts. Everything necessary to shift between the two configurations is included, as well as a vertical GPU mount (complete with a Gen 4.0 riser cable).
AIRFLOW AT ANOTHER LEVEL
High airflow panels surround the MORPHEUS WH case from the front, right, top, bottom, rear, and even the top of the PSU shroud; there will be no shortage of airflow provided to the high-powered heat-generating components inside. High-flow mesh filters are included for the front, top, and bottom panels and will keep dust out.
EXTENSIVE COOLING CAPABILITY
Fan options are unparalleled, with the ability to mount thirteen 120mm or 140mm fans or go to the extreme and add up to six 200mm fans into the conversation. The highly modular fan rails make these configurations a reality.
The MORPHEUS WH can also support up to three 420mm radiators simultaneously. 420mm radiators can be mounted to the front, top, bottom, and side of the motherboard tray.
A TRINITY OF FANS!
A set of highly convenient trinity fans come mounted inside the MORPHEUS WH: three beautifully bright 140mm ARGB fans are united into a single 420mm unit. The trinity of fans only require the wiring of a single set of PWM and ARGB cables, greatly reducing the amount of cable management.
MAXIMUM COMPATIBILITY
The ATX+ form factor of the MORPHEUS WH case guarantees compatibility with a large range of components. This ATX+ DeepCool case supports E-ATX motherboards while also having compatibility for GPUs up to 480mm in length, 195mm tall CPU coolers in the single chamber configuration, and multiple 420mm radiators.
DUAL REAL-TIME DIGITAL DISPLAY
Save precious space on your desktop by moving the monitoring of temperatures and usage of your CPU and GPU onto the built-in display that is included with the MORPHEUS WH case. A simple-to-install app and an open USB 2.0 header will get the dual display up and running.
A BEVY OF I/O PORTS
With four USB 3.0 ports, a Type-C port, and a hybrid audio port, there is no shortage of devices that can be accessed from the top front I/O panel. There is also an LED cycle button to control the built-in ARGB controller, an HDD activity LED, and a Power button to round out the front I/O.
BITS!
Add a bit of a personal touch with the fun rubber square bits! Included as a fun addition, the pixels can be used with majority of the mesh panels of the MORPHEUS WH case. Leave messages for others, add custom logos, or create your own 8-bit character!
| Design | |
|---|---|
| Maximum PSU length | 18 cm |
| Maximum graphics card length | 48 cm |
| Maximum CPU cooler height | 19.5 cm |
| LED indicators | Yes |
| On/off button | Yes |
| Cable management | Yes |
| Anti-dust filter | Yes |
| Tempered glass panel(s) | Yes |
| Illumination location | Case fans |
| Illumination colour | Multi |
| Illumination | Yes |
| Suitable for | Gaming |
| Side window | Yes |
| Number of expansion slots | 9 |
| Number of internal 3.5″ bays | 2 |
| Number of 2.5″ bays | 3 |
| Number of 3.5″ bays | 2 |
| Supported motherboard form factors | ATX, micro ATX, Mini-ATX, EATX |
| Product colour | White |
| Material | ABS, SPCC, Tempered glass |
| Type | PC |
| Form factor | Tower |
| Power supply | |
|---|---|
| Supported power supply form factors | ATX |
| Power supply location | Bottom |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Cooling | |
|---|---|
| Top radiator sizes supported | 140,240,360,120,280,420 mm |
| Rear radiator sizes supported | 120,140 mm |
| Bottom radiator sizes supported | 140,240,360,120,280,420 mm |
| Side radiator sizes supported | 140,240,360,120,280,420 mm |
| Front radiator sizes supported | 140,240,360,120,280,420 mm |
| Bottom fans diameters supported | 120,180,140,200 mm |
| Number of bottom fans supported (max) | 3 |
| Top fans diameters supported | 120,180,140,200 mm |
| Number of top fans supported (max) | 3 |
| Rear fans diameters supported | 140,120 mm |
| Number of rear fans supported (max) | 1 |
| Side fans diameters supported | 140,120 mm |
| Number of side fans supported (max) | 3 |
| Front fans diameters supported | 120,180,140,200 mm |
| Number of front fans supported (max) | 3 |
| Storage | |
|---|---|
| SSD form factor | 2.5″ |
| Supported HDD sizes | 2.5,3.5″ |
| Weight & dimensions | |
|---|---|
| Weight | 15.5 kg |
| Height | 551 mm |
| Depth | 528 mm |
| Width | 250 mm |
