Intel BNUC11ATBC40S00
Intel® AES New Instructions
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Intel vPro® Platform Eligibility
The Intel vPro® platform is a set of hardware and technologies used to build business computing endpoints with premium performance, built-in security, modern manageability and platform stability.
Intel® HD Audio Technology
Intel® High Definition Audio (Intel® HD Audio) is capable of playing back more channels at higher quality than previous integrated audio formats. In addition, Intel® HD Audio has the technology needed to support the latest and greatest audio content.
Integrated Graphics
Integrated graphics allow for incredible visual quality, faster graphic performance and flexible display options without the need for a separate graphics card.
Intel® Platform Trust Technology (Intel® PTT)
Intel® Platform Trust Technology (Intel® PTT) is a platform functionality for credential storage and key management used by Windows 8* and Windows® 10. Intel® PTT supports BitLocker* for hard drive encryption and supports all Microsoft requirements for firmware Trusted Platform Module (fTPM) 2.0.
| Processor | |
|---|---|
| Processor boost frequency | 2.9 GHz |
| Processor threads | 4 |
| Processor cores | 4 |
| Thermal Design Power (TDP) | 15 W |
| Processor lithography | 10 nm |
| Processor cache | 4 KB |
| Processor model | Celeron N5105 |
| Processor manufacturer | Intel |
| Processor frequency | 2 MHz |
| Memory | |
|---|---|
| Number of DIMM slots | 2 |
| Internal storage capacity | 64 GB |
| Storage location | Internal |
| SSD form factor | M.2 |
| eMMC capacity | 64 GB |
| ECC | No |
| Memory channels | Dual-channel |
| Memory clock speed | 2933 MHz |
| Internal memory type | DDR4-SDRAM |
| Maximum internal memory | 32 GB |
| Ports & interfaces | |
|---|---|
| Number of M.2 (M) slots | 1 |
| HDMI ports quantity | 1 |
| Number of M.2 (E) slots | 1 |
| Headphone out | Yes |
| Audio port type | 3.5mm |
| USB ports quantity | 6 |
| USB version | 2.0/3.2 Gen 2 (3.1 Gen 2) |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Graphics | |
|---|---|
| On-board graphics card | No |
| Number of displays supported | 2 |
| Software | |
|---|---|
| Windows operating systems supported | Windows 11, Windows 10 |
| Power | |
|---|---|
| DC input voltage | 19 V |
| Weight & dimensions | |
|---|---|
| Board dimensions | 121.6 x 108.55 mm |
| Other features | |
|---|---|
| Status | Launched |
| Launch date | Q1’22 |
| Commodity Classification Automated Tracking System (CCATS) | G157815L2 |
| Export Control Classification Number (ECCN) | 5A992C |
| PCI Express slots version | 3.0 |
| Supported memory types | DDR4-SDRAM |
| Number of storage drives supported | 1 |
| Processor family | Intel® Celeron® N |
| Operational conditions | |
|---|---|
| Operating temperature (T-T) | 0 – 35 °C |
| Processor special features | |
|---|---|
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® vPro™ Platform Eligibility | No |
| Logistics data | |
|---|---|
| Harmonized System (HS) code | 8471500150 |
