Intel Core i3-1320PRE processor 1.7 GHz 12 MB Smart Cache
- Intel® Core™ i3 i3-1320PRE 1.7 GHz
- 12 MB Smart Cache BGA 1744
- Processor cores: 8 28 W
- Maximum internal memory supported by processor: 96 GB LPDDR5x-SDRAM, DDR4-SDRAM, DDR5-SDRAM, LPDDR4x-SDRAM, LPDDR5-SDRAM
- On-board graphics card Intel® UHD Graphics
| Processor | |
|---|---|
| Processor ARK ID | 235072 |
| Processor codename | Raptor Lake |
| Minimum Assured Power | 20 W |
| Minimum Assured Frequency | 1.2 GHz |
| Maximum Assured Frequency | 2.2 GHz |
| Maximum Assured Power | 35 W |
| Processor base power | 28 W |
| Maximum turbo power | 64 W |
| Thermal Design Power (TDP) | 28 W |
| Processor cache type | Smart Cache |
| Processor cache | 12 MB |
| Efficient-core boost frequency | 3.3 GHz |
| Performance-core boost frequency | 4.5 GHz |
| Processor boost frequency | 4.5 GHz |
| Efficient cores | 4 |
| Performance cores | 4 |
| Processor threads | 12 |
| Box | No |
| Processor socket | BGA 1744 |
| Processor cores | 8 |
| Processor base frequency | 1.7 GHz |
| Processor model | i3-1320PRE |
| Processor generation | Intel Core i3-13xxx |
| Processor family | Intel® Core™ i3 |
| Processor manufacturer | Intel |
| Memory | |
|---|---|
| ECC | Yes |
| Memory channels | Dual-channel |
| Memory clock speeds supported by processor | 3200,4267,5200,6400 MHz |
| Memory types supported by processor | LPDDR5x-SDRAM, DDR4-SDRAM, DDR5-SDRAM, LPDDR4x-SDRAM, LPDDR5-SDRAM |
| Maximum internal memory supported by processor | 96 GB |
| Graphics | |
|---|---|
| Multi-Format Codec Engines | 1 |
| Number of execution units | 48 |
| Discrete graphics card model | Not available |
| On-board graphics card ID | 0xA7A8 |
| On-board graphics card refresh rate at maximum resolution (DisplayPort) | 60 Hz |
| On-board graphics card refresh rate at maximum resolution (eDP – Integrated Flat Panel) | 120 Hz |
| On-board graphics card refresh rate at maximum resolution (HDMI) | 60 Hz |
| On-board graphics card maximum resolution (DisplayPort) | 7680 x 4320 pixels |
| On-board graphics card maximum resolution (eDP – Integrated Flat Panel) | 4096 x 2304 pixels |
| On-board graphics card maximum resolution (HDMI) | 4096 x 2304 pixels |
| On-board graphics card DirectX version | 12.1 |
| On-board graphics card OpenGL version | 4.6 |
| Number of displays supported (on-board graphics) | 4 |
| On-board graphics card dynamic frequency (max) | 1200 MHz |
| On-board graphics card outputs supported | Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1 |
| On-board graphics card model | Intel® UHD Graphics |
| On-board graphics card | Yes |
| Discrete graphics card | No |
| Features | |
|---|---|
| Embedded options available | Yes |
| CPU configuration (max) | 1 |
| Functional safety (FuSa) documentation available | No |
| Supported instruction sets | AVX 2.0, SSE4.1, SSE4.2 |
| PCI Express slots version | 4.0 |
| Maximum number of PCI Express lanes | 20 |
| Use conditions | Industrial Extended Temp |
| Market segment | Embedded |
| Execute Disable Bit | Yes |
| Thermal Monitoring Technologies | Yes |
| Processor special features | |
|---|---|
| Intel® Threat Detection Technology (TDT) | Yes |
| MIPI SoundWire | 1.2 |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Mode-based Execute Control (MBE) | Yes |
| Intel® Secure Key | Yes |
| Intel® OS Guard | Yes |
| Intel® Boot Guard | Yes |
| Intel® High Definition Audio (Intel® HD Audio) | Yes |
| Intel® Smart Sound Technology | Yes |
| Chipset / PCH PCIe Revision | Gen 3 |
| Microprocessor PCIe Revision | Gen 4 |
| Intel® Thread Director | Yes |
| Intel® Control-flow Enforcement Technology (CET) | Yes |
| Intel® Image Processing Unit | 6.0 |
| Intel® Wake on Voice | Yes |
| Intel® Thunderbolt 4 | Yes |
| Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0 | Yes |
| Intel® Time Coordinated Computing (Intel® TCC) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Quick Sync Video Technology | Yes |
| Intel Flex Memory Access | Yes |
| General | |
|---|---|
| Product family | Core |
| Product series | i3 |
| Operational conditions | |
|---|---|
| Maximum operating temperature | 100 °C |
| Tjunction | 100 °C |
| Technical details | |
|---|---|
| Launch date | Q1’23 |
| Status | Launched |
| OpenCL version | 3.0 |
| Weight & dimensions | |
|---|---|
| Processor package size | 50 x 25 mm |
| Other features | |
|---|---|
| Graphics output | eDP 1.4b, DP 1.4a, HDMI 2.1 |
| Maximum internal memory | 96 GB |
