Lenovo ThinkSystem SR250 V3 server Rack (1U) Intel Xeon E E-2468 2.6 GHz 32 GB DDR5-SDRAM 800 W
- Intel Xeon E-2468 (24MB Cache, 2.6GHz)
- 32GB (4800MHz) DDR5-SDRAM (1 x 32)
- XClarity Administrator
The Lenovo ThinkSystem SR250 V3 is a high-value single-socket 1U rack server for growing businesses that need optimized performance and flexibility for future growth, along with enterprise-class reliability, management, and security. The server supports the new Intel Xeon E-2400 Series processors, formerly codenamed “Raptor Lake-E”.
This product guide provides essential presales information to understand the ThinkSystem SR250 V3 server, its key features and specifications, components and options, and configuration guidelines. This guide is intended for technical specialists, sales specialists, sales engineers, IT architects, and other IT professionals who want to learn more about the SR250 V3 and consider its use in IT solutions.
| Processor |
| Number of processors installed |
1 |
| Motherboard chipset |
Intel C266 |
| Processor cache |
24 MB |
| Processor cores |
8 |
| Performance cores |
8 |
| Processor boost frequency |
5.2 GHz |
| Processor frequency |
2.6 GHz |
| Processor model |
E-2468 |
| Processor family |
Intel Xeon E |
| Processor manufacturer |
Intel |
| Memory |
| Maximum internal memory |
128 GB |
| Memory slots |
4x DIMM |
| ECC |
Yes |
| Memory clock speed |
4800 MHz |
| Memory layout (slots x size) |
1 x 32 GB |
| Internal memory type |
DDR5-SDRAM |
| Internal memory |
32 GB |
| Storage |
| Internal drive bays |
8 |
| Supported storage drive interfaces |
SAS, Serial ATA |
| Supported RAID controllers |
5350-8i |
| RAID levels |
0, 1, 5, 10 |
| RAID support |
Yes |
| Graphics |
| Maximum graphics card memory |
16 MB |
| On-board graphics card |
Yes |
| Network |
| LAN controller |
Broadcom BCM5720 |
| Ethernet LAN |
Yes |
| Cabling technology |
10/100/1000Base-T(X) |
| Ethernet interface type |
Gigabit Ethernet |
| Ports & interfaces |
| VGA (D-Sub) ports quantity |
1 |
| Serial ports quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
3 |
| USB 2.0 ports quantity |
2 |
| Ethernet LAN (RJ-45) ports |
2 |
| Design |
| Product colour |
Black, Silver |
| Chassis type |
Rack (1U) |
| Performance |
| Trusted Platform Module (TPM) |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Remote administration |
XClarity Administrator |
| Software |
| Compatible operating systems |
Microsoft Windows ServerRed Hat Enterprise LinuxSUSE Linux Enterprise ServerVMware ESXi |
| Power |
| Power supply input frequency |
50/60 Hz |
| Power supply input voltage |
100 – 240 V |
| Power supply |
800 W |
| Redundant power supply (RPS) support |
Yes |
| Operational conditions |
| Operating altitude |
0 – 3050 m |
| Storage relative humidity (H-H) |
8 – 90% |
| Storage temperature (T-T) |
-40 – 60 °C |
| General |
| Product family |
ThinkSystem |
| Weight & dimensions |
| Depth |
561 mm |
| Height |
43 mm |
| Width |
434.4 mm |
| Technical details |
| Supported storage drives form factor (rear) |
2.5″ |
