Linksys LGS116P-UK network switch Unmanaged L7 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Black
- Unmanaged L7
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 16
- 1000BASE-T, 100BASE-TX, 10BASE-T
- MAC address table: 8000 entries
- Power over Ethernet (PoE)
Features:
– Wired connection speed up to 1,000 Mbps
– 16 Gigabit Ethernet autosensing ports
– Quality of Service (QoS) traffic prioritization
– Power over Ethernet (PoE) support
– Easy plug & play connection
| Management features |
| Quality of Service (QoS) support |
Yes |
| Switch layer |
L7 |
| Switch type |
Unmanaged |
| Ports & interfaces |
| Gigabit Ethernet (copper) ports quantity |
16 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity |
16 |
| Network |
| Auto-sensing |
Yes |
| Flow control support |
Yes |
| Copper ethernet cabling technology |
1000BASE-T, 100BASE-TX, 10BASE-T |
| 10G support |
No |
| Networking standards |
IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Data transmission |
| Throughput |
1.488 Mpps |
| MAC address table |
8000 entries |
| Design |
| LED indicators |
Yes |
| Product colour |
Black |
| Rack mounting |
No |
| Power |
| Power consumption (typical) |
11.31 W |
| Input current |
1.66 A |
| Number of power supply units |
1 |
| Power over Ethernet (PoE) |
| Total Power over Ethernet (PoE) budget |
80 W |
| Power over Ethernet plus (PoE+) ports quantity |
8 |
| Power over Ethernet (PoE) |
Yes |
| Other features |
| Bandwidth |
32 Gbit/s |
| Operational conditions |
| Storage relative humidity (H-H) |
10 – 90% |
| Operating relative humidity (H-H) |
10 – 90% |
| Storage temperature (T-T) |
-40 – 70 °C |
| Operating temperature (T-T) |
0 – 50 °C |
| Weight & dimensions |
| Weight |
822 g |
| Height |
25 mm |
| Depth |
120 mm |
| Width |
280 mm |
| Certificates |
| Certification |
FCC Class A, CE |
| Logistics data |
| Harmonized System (HS) code |
85176990 |
