RAIJINTEK Ophion M Evo TGS Midi Tower Black, Transparent
- Support Micro-ATX / Mini ITX
- 2mm aluminum & 0.8mm SPCC solid iron
- Matte full black coating
- 3.0mm tempered glass side panel
- Water radiator support up to 120/240/280/360, 28mm thick water radiator
- Super air flow, support up to 3×200mm fans in total (2×20030 fans at top, 1×20030 fan in bottom)
- Support up to 410mm full-length graphic cad
- Maximum CPU cooler height up to 82mm
- Capable of install motor/water tank to achieve real /DIY water loop system
- Magnetic dust filter for both top & bottom
Design Art in its best by RAIJINTEK – New SFF chassis of OPHION series. The OPHION series case is designed to fulfil a smallest case built with max. Possibility high-end, gaming and standard components, such as Intel i9/i7, AMD AM4/TR4 CPU, and especially powerful full –length VGA card, RTX2080. OPHION M EVO case supports up to M-ATX motherboard, Amazing compatibility of maximum three fans including 2*12025 or 2*14025 or 2*20030 fans on top, 1*12015 fan or 1*14025 or 1*20030 fans at bottom. Not only cooling from fans, it also support DIY component such as 120/140/240/280/360 28mm thickness radiator and also enough space for pump and reservoir as well. OPHION M EVO Superior features includes elegant Alu. Hair-silk front panel, 3.5”*3 HDD or 2.5”*5 HDD/SSD, full-length VGA card compatibility, tool-free for the easy installation, ATX / EPS PSU compatibility. Looking for a best of best? OPHION M EVO is the one for Gamers and SFF DIY water cooling enthusiasts.
| Design | |
|---|---|
| Maximum graphics card length | 41 cm |
| Maximum CPU cooler height | 8.2 cm |
| Anti-dust filter | Yes |
| Tempered glass panel(s) | Yes |
| Side window | Yes |
| Number of expansion slots | 2 |
| Number of storage drives supported | 5 |
| Number of internal 3.5″ bays | 3 |
| Number of 2.5″ bays | 5 |
| Number of 3.5″ bays | 3 |
| Supported motherboard form factors | micro ATX, Mini-ITX |
| Product colour | Black, Transparent |
| Material | Aluminium, Tempered glass |
| Type | PC |
| Form factor | Midi Tower |
| Power supply | |
|---|---|
| Supported power supply form factors | PS2 |
| Power supply location | Bottom |
| Power supply included | No |
| Ports & interfaces | |
|---|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Cooling | |
|---|---|
| Liquid cooling capability | Yes |
| Bottom fans diameters supported | 120,140,200 mm |
| Number of bottom fans supported (max) | 1 |
| Top fans diameters supported | 120,140,200 mm |
| Number of top fans supported (max) | 2 |
| Storage | |
|---|---|
| Number of HDDs supported | 5 |
| HDD/SSD combo cage | Yes |
| Supported HDD sizes | 2.5,3.5″ |
| Weight & dimensions | |
|---|---|
| Weight | 5.89 kg |
| Height | 365 mm |
| Depth | 453 mm |
| Width | 231 mm |
| Packaging data | |
|---|---|
| Package weight | 6.37 kg |
| Cables included | PCIe |
