TieDex UK APC Back-UPS BX Series BX1200MI – UPS – 650 Watt – 1200 VA
APC Back-UPS BX Series BX1200MI – UPS – AC 230 V – 650 Watt – 1200 VA – 9 Ah – output connectors: 6
Basic Specifications
- Manufacturer’s Part Number
- BX1200MI
- EAN
- 0731304410812
- Manufacturer Warranty
- 2-year warranty
- Product Description
- APC Back-UPS BX Series BX1200MI – UPS – 650 Watt – 1200 VA
- Model
- APC Back-UPS BX Series BX1200MI
- Weight
- 7.6 kg
- Input Connectors
- 1 x power IEC 60320 C14
- Device Type
- UPS – external
- Battery
- Lead Acid – 9 Ah
- Dimensions (WxDxH)
- 14 cm x 39 cm x 19 cm
- Power Capacity
- 650 Watt / 1200 VA
- Output Voltage
- AC 230 V ± 10%
- Output connectors
- 6 x power IEC 60320 C13
- Run Time (Up To)
- 5 min at half load
- Input Voltage
- AC 230 V
- Batteries Qty
- 1
General
- Device Type
- UPS – external
Expansion / Connectivity
- Interfaces
- 1 x USB
Dimensions & Weight (Shipping)
- Shipping Width
- 23.5 cm
- Shipping Depth
- 49.5 cm
- Shipping Height
- 29.7 cm
- Shipping Weight
- 8.6 kg
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 40 °C
- Humidity Range Operating
- 0 – 95%
Dimensions & Weight
- Width
- 14 cm
- Depth
- 39 cm
- Height
- 19 cm
- Weight
- 7.6 kg
Miscellaneous
- Features
- Automatic Voltage Regulation (AVR), audible alarm
- Compliant Standards
- EN 62040-1, CB, IEC 62040-1, IEC 62040-2, IP20
Battery
- Quantity
- 1
- Technology
- Lead Acid
- Voltage Provided
- 12 V
- Capacity
- 9 Ah
- Run Time (Up To)
- 5 min at 50% load ¦ 1 min at full load
- Recharge Time
- 8 hours
- Transfer Time
- 6 ms
- Features
- Maintenance free, sealed
Manufacturer Warranty
- Service & Support
- Limited warranty – replace or repair – 2 years
Power Device
- UPS Technology
- Line interactive
- Input Voltage
- AC 230 V
- Input Voltage Range
- AC 140 – 300 V
- Frequency Provided
- 50/60 Hz
- Frequency Required
- 50/60 Hz
- Input Connectors
- 1 x power IEC 60320 C14
- Power Output Connectors Details
- 6 x power IEC 60320 C13
- Output Voltage
- AC 230 V ± 10% – 50/60 Hz
- Power Capacity
- 650 Watt / 1200 VA
- Dataline Surge Protection
- Network – RJ-45 – 1 input line / 1 output line
- Output Waveform
- Stepped approximation to a sinewave
- Surge Energy Rating
- 273 Joules
- Circuit Protection
- Fuse
