TieDex UK ASUS PRIME B550-PLUS – motherboard – ATX – Socket AM4 – AMD B550
ASUS PRIME B550-PLUS – Motherboard – ATX – Socket AM4 – AMD B550 Chipset – USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2 – Gigabit LAN – onboard graphics (CPU required) – HD Audio (8-channel)
Basic Specifications
- Manufacturer’s Part Number
- 90MB14U0-M0EAY0
- EAN
- 4718017782340
- Manufacturer Warranty
- 3-year warranty
- Product Description
- ASUS PRIME B550-PLUS – motherboard – ATX – Socket AM4 – AMD B550
- Model
- ASUS PRIME B550-PLUS
- Product Type
- Motherboard – ATX
- Form Factor
- ATX
- Audio
- HD Audio (8-channel)
- RAM Supported
- 4 DIMM slots – DDR4, non-ECC, ECC, unbuffered
- Compatible Processors
- Ryzen (supports 3rd Generation Ryzen)
- Max RAM Size
- 128 GB
- Processor Socket
- 1 x Socket AM4
- USB / FireWire Ports
- 1 x USB-C Gen 2 + 1 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
- Chipset Type
- AMD B550
- Storage Ports
- 6 x SATA-600 (RAID), 2 x M.2
- LAN
- Gigabit Ethernet
Features
- BIOS Type
- AMI
- BIOS Features
- UEFI BIOS, ASUS EZ Flash 3
- Sleep / Wake Up
- Wake on LAN (WOL), wake on PME
- Hardware Features
- Jack retasking, ASUS Q-Design, ESD Guards, ASUS TurboV EVO, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, CrashFree BIOS 3, audio jack detect technology, ASUS EPU (Energy Processing Unit), ASUS DIGI+ VRM, AMD CrossFireX technology support, ASUS Enhanced DRAM Overcurrent Protection, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, LANGuard, ASUS Overvoltage Protection, ASUS Fan Xpert 4, ASUS 5X Protection III, ASUS SafeSlot Core, ASUS Aura Sync, Armoury Crate
General
- Product Type
- Motherboard – ATX
- Chipset Type
- AMD B550
- Processor Socket
- Socket AM4
- Max Processors Qty
- 1
- Compatible Processors
- Ryzen (supports 3rd Generation Ryzen)
Audio
- Type
- HD Audio (8-channel)
- Audio Codec
- Realtek ALC887
- Compliant Standards
- High Definition Audio
Expansion / Connectivity
- Expansion Slots
- 1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 3.0 x16 (x4 mode) ¦ 3 x PCIe 3.0 x1
- Storage Interfaces
- SATA-600 -connectors: 6 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2
- Interfaces
- 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 3.2 Gen 1 ¦ 1 x audio line-in – mini-jack ¦ 1 x audio line-out – mini-jack ¦ 1 x microphone – mini-jack ¦ 1 x USB-C Gen2 ¦ 1 x USB 3.2 Gen 2 ¦ 1 x TOSLINK ¦ 1 x audio line-out (center/subwoofer) – mini-jack ¦ 1 x audio line-out (rear) – mini-jack ¦ 2 x USB 2.0 ¦ 1 x DisplayPort ¦ 1 x HDMI
- Internal Interfaces
- 4 x USB 2.0 – header ¦ 2 x USB 3.2 Gen 1 – header ¦ 1 x Thunderbolt – header ¦ 1 x audio – header ¦ 1 x serial – header
- Power Connectors
- 24-pin main power connector, 8-pin ATX12V connector
Miscellaneous
- Included Accessories
- 1 x M.2 screw, I/O back cover
- Cables Included
- 2 x Serial ATA cable
- Software Included
- Drivers & Utilities, ASUS CPU-Z, ASUS AI Suite III, ASUS EZ Update, DAEMON Tools, WinRAR, Norton AntiVirus (60 days trial)
- Width
- 30.5 cm
- Depth
- 24.4 cm
Manufacturer Warranty
- Service & Support
- Limited warranty – 3 years
LAN
- Network Controller
- Realtek RTL8111H
- Network Interfaces
- Gigabit Ethernet
Supported RAM
- Max Size
- 128 GB
- Technology
- DDR4
- Bus Clock
- 2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3466 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4400 MHz (O.C.), 3200 MHz
- Supported RAM Integrity Check
- Non-ECC, ECC
- Registered or Buffered
- Unbuffered
- Features
- Dual channel memory architecture
