TieDex UK Owl Labs Owl Bar – video conferencing device
Owl Labs Owl Bar – Video conferencing device – Certified for Microsoft Teams – grey
Basic Specifications
- Manufacturer’s Part Number
- FRS100-2000
- EAN
- 0850022203602
- Networking
- Network adapter – Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 802.11ax
- Video Input
- Digital video camera – USB
- Codec
- MJPEG, NV12, NV21, YUY2
- Model
- Owl Labs Owl Bar
- System Requirements
- Apple MacOS, Windows, Google Chrome OS, Linux
- Device Type
- Video conferencing device
- Dimensions (WxDxH)
- 76.9 cm x 9.7 cm x 7.6 cm
- Localisation
- United Kingdom, Europe
- Manufacturer Warranty
- 2-year warranty
- Weight
- 1.88 kg
- Audio Output
- Speaker(s)
- Product Description
- Owl Labs Owl Bar – video conferencing device
- Audio Input
- 4 microphones – beamforming
- Software Certification
- Certified for Microsoft Teams
Networking
- Type
- Network adapter
- Connectivity Technology
- Wired, wireless
- Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, 802.11ax
- Features
- Secure boot
Dimensions & Weight (Shipping)
- Shipping Width
- 14.9 cm
- Shipping Depth
- 82 cm
- Shipping Height
- 16.2 cm
- Shipping Weight
- 5 kg
Expansion / Connectivity
- Interfaces
- 1 x audio / video – HDMI input ¦ 1 x audio / video – HDMI output ¦ 1 x USB-C 3.0 – 24 pin USB-C ¦ 1 x SuperSpeed USB 3.0 – 9 pin USB Type A ¦ 1 x network – Ethernet 10Base-T/100Base-TX/1000Base-T – RJ-45
Video Input
- Type
- Digital video camera (colour) – integrated
- Interface Type
- USB
- Digital Video Capture Resolution
- 3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 720, 640 x 360
- Video Modes
- 4K
- Features
- Digital PTZ function, Auto Focus, PTZ Auto Framing, Google Meet compatible, Microsoft Teams compatible, Slack compatible, Zoom compatible, 114° field of view (horizontal), 30 megapixels, 73° field of view (vertical), 30 fps, USB Video Communication Protocol (UVC 1.0)
Power
- Power Device
- Power adapter – external
Environmental Parameters
- Min Operating Temperature
- 0 °C
- Max Operating Temperature
- 35 °C
- Humidity Range Operating
- 10 – 90%
General
- Device Type
- Video conferencing device
- Video Codecs
- MJPEG, NV12, NV21, YUY2
- Width
- 76.9 cm
- Depth
- 9.7 cm
- Height
- 7.6 cm
- Weight
- 1.88 kg
- Enclosure Colour
- Grey
- Localisation
- United Kingdom, Europe
Manufacturer Warranty
- Service & Support
- Limited warranty – 2 years
Miscellaneous
- Cables Included
- 1 x USB-C cable – 1.83 m ¦ 1 x HDMI cable – 1.83 m
- Included Accessories
- Table stand, Owl card holder, Owl Connect card, Owl Labs sticker
- Software Certification
- Certified for Microsoft Teams
Software / System Requirements
- Software Included
- Owl Intelligence System
- OS Required
- Apple MacOS, Windows, Google Chrome OS, Linux
Audio Output
- Type
- Speaker(s)
- Output Power / Channel
- 5 Watt
Audio Input
- Type
- 4 microphones – integrated
- Microphone Operation Mode
- Beamforming
- Frequency Response
- 100 – 10000 Hz
- Total Harmonic Distortion (THD)
- <1%
