Toshiba MG09 internal hard drive 14 TB 7200 RPM 3.5″ Serial ATA III
- Up to 18TB capacity
- Conventional Magnetic Recording (CMR) for broad compatibility
- Toshiba Flux Control Microwave-assisted Magnetic Recording (FC-MAMR) Technology
- Industry-leading 9-disk helium-sealed design for superior storage density
- Industry Standard 3.5-inch 26.1mm height Form Factor
- 7200rpm Performance
- Choice of SATA 6.0 Gbit/s and 12.0 Gbit/s SAS Interfaces
- Lower operational power profile, providing excellent power efficiency (W/TB) for better TCO
- 550 Total TB Transferred per Year Workload Rating
- 512e or 4Kn Advanced Format Sector Technology; (512e Model) Includes Toshiba Persistent Write Cache Technology for Data-Loss Protection in Sudden Power-Loss Events
- Sustained transfer rate and power efficiency improvements vs. prior MG Series generations
- Sanitize Instant Erase (SIE) option model and Self Encrypting Drive (SED) option model
- Cloud-scale Sever and Storage Infrastructure
- Software-defined data center infrastructure
- File- and Object-based storage infrastructure
- Tiered Storage Infrastructure Solutions
- Workloads and Use-Cases that Benefit from High Capacity per Spindle disk drives
- Capacity-Optimized Cloud-scale and Rack-Scale Storage Systems
- Compliance Data Archives and Data Life-Cycle Management Storage Systems
- Data Center Data-Protection and Data Back-up Infrastructure
Rethink Your Data Storage Toshiba Enterprise HDDs
The MG09 Series features Toshiba’s third-generation, 9-disk Helium-sealed design to advance Conventional Magnetic Recording (CMR) density to 2 TB per disk, achieving a total capacity up to 18TB. The industry-standard 3.5-inch form-factor provides 7200rpm performance, and integrates easily into cloud-scale storage infrastructure, business-critical servers and storage, and File and Object storage solutions.
The massive 18 TB CMR capacity is delivered using Toshiba’s innovative Flux Control Microwave Assisted Magnetic Recording (FC-MAMR) technology. These advances help the MG09 Series to achieve optimum storage capacity and application compatibility, with unsurpassed data reliability. Available with either a SATA 6.0 Gbit/s or a 12.0 Gbit/s SAS interface, the MG09 Series models integrate easily into standard 3.5-inch drive bays to help reduce the footprint and operational burden of cloud-scale storage infrastructure, File and Object storage systems, and business critical servers and storage systems.
| Features | |
|---|---|
| Mean time to failure (MTTF) | 2500000 h |
| Noise level (idle) | 20 dB |
| Workload rate limit | 550 TB/year |
| Start/stop cycles | 600000 |
| 24/7 operation | Yes |
| Advanced Format (AF) | Yes |
| Uncorrectable Bit Error Rate (UBER) | < 1 per 10^10 bits read |
| HDD sustained transfer rate | 268 MiB/s |
| HDD interface transfer rate | 6 Gbit/s |
| Hot-swap | No |
| Component for | NAS |
| Type | HDD |
| Interface | Serial ATA III |
| HDD size | 3.5″ |
| HDD speed | 7200 RPM |
| HDD capacity | 14 TB |
| Power | |
|---|---|
| Operating voltage | 5 / 12 V |
| Power consumption (idle) | 3.77 W |
| Power consumption (typical) | 7.96 W |
| Operational conditions | |
|---|---|
| Non-operating shock | 250 G |
| Operating shock | 70 G |
| Non-operating altitude | -305 – 12192 m |
| Operating altitude | -305 – 3048 m |
| Non-operating vibration | 3 G |
| Operating vibration | 0.75 G |
| Storage relative humidity (H-H) | 5 – 95% |
| Operating relative humidity (H-H) | 5 – 90% |
| Storage temperature (T-T) | -40 – 70 °C |
| Operating temperature (T-T) | 5 – 55 °C |
| Packaging data | |
|---|---|
| Quantity per pack | 1 pc(s) |
