Transcend 512MB CF 0.512 GB CompactFlash
- 0.512 GB CompactFlash
- 40 MB/s
- Black
Built extra-rugged with excellent temperature flexibility and high performance, Transcend’s CF220I Industrial Temp CF cards are specifically designed for industrial use and mission-critical applications.
– CompactFlash Specification Version 4.1 compliant
– RoHS compliant
– Supports S.M.A.R.T (Self-defined)
– Supports Security Command
– Supports Global Wear-Leveling, Static Data Refresh, Early Retirement, and Erase Count Monitor functions to extend product life
– Operation Modes: PC Card Memory, PC Card IO, True IDE
– True IDE Mode supports: UDMA0-5, MDMA0-4, PIO0-6 (UDMA5 as default)
– True IDE Mode: Fixed Disk (Default)
– PC Card Mode: Fixed Disk (Default)
– Advanced Power Shield prevents data loss in the event of a sudden power outage
| Memory |
| Write speed |
42 MB/s |
| Read speed |
40 MB/s |
| Flash card type |
CompactFlash |
| Capacity |
0.512 GB |
| Features |
| Mean time between failures (MTBF) |
4000000 h |
| Product colour |
Black |
| Power |
| Memory voltage |
3.3,5 V |
| Operational conditions |
| Operating relative humidity (H-H) |
0 – 95% |
| Storage temperature (T-T) |
-55 – 100 °C |
| Operating temperature (T-T) |
-40 – 85 °C |
| Weight & dimensions |
| Height |
3.3 mm |
| Depth |
42.8 mm |
| Width |
36.4 mm |
| Packaging data |
| Quantity per pack |
1 pc(s) |
| Other features |
| Compliance certificates |
RoHS |
